Paper laminating machine SUNNY MACHINERY

Payment Type: L/C,T/T
Incoterm: FOB,CIF
Min. Order: 1 Set/Sets
Delivery Time: 180 Days

Basic Info

Model No.: GF1400

Laminating Type: Dry-method Laminating

Laminating Material: BOPP 20-60μm; CPP 20-60μm; PE 30-60μm; Combination

Film Width: Max.1400mm

Coating Glue Type: Gravure Coating Directly

Machine Speed: Max.180m/min

Operation Speed: Max.150m/min

Guide Roller Width: 1300mm

1st Unwind Diameter: Max. φ 600mm

2nd Unwind Diameter: Max. φ 600mm

Rewind Diameter: Max. φ 800mm

Additional Info


Productivity: 180m/min

Brand: SUNNY

Transportation: Ocean

Place of Origin: CHINA

Supply Ability: 100 SETS PER YEAR

Certificate: CE

HS Code: 8477


Product Description

Paper laminating machine SUNNY MACHINERY GF1400

Paper laminating machine SUNNY MACHINERY GF1400 is the elaborately manufactured product we referring to the advanced technology and experiences at domestic and abroad. Complete machine structure is reasonable, high machining precision, PLC programmable controller, electric components are all adopting the first-class high quality products of abroad, ensured the quality stabilization of equipment. compared with the similarity products of abroad, and machine performance has achieved the advanced level.


This machine is biaxially oriented film by coating gluing, dry solidification, and with other functional, heat sealing film laminating dedicated equipment, it is the key equipment in process for printing the laminating film product.

Main technical parameters

1). Lamination type: Dry-method laminating

2). Laminating material: adaptation material range

BOPP   20-60μm;   CPP      20-60μm;    PE    30-60μm;

PET    20-45μm;   NYLON     12-38μm;   7-12μm

combination film  20-60μm; cellophane   20-30μm

3). Film width: Max.1400mm

4). Coating glue type: gravure coating directly

5). Coating glue volume: By web roller line number and glue consistency control

6). Machine speed: Max.180m/min

7). Operation speed: Max.150m/min

8). Guide roller width: 1300mm

10). 1st unwind diameter: Max. φ 600mm

11). 2nd unwind diameter: Max. φ 600mm

12). Rewind diameter: Max. φ 800mm

dry laminating machine details

slitting machine

slitting machine

Extrusion laminating machine

slitting machine ce

Company Information:

Sunny Machinery Factory is an integrated professional manufacturer to produce, design and sell Slitting, Rewinding, Laminating, Coating, and CPP or CPE 3 or multiple layers Cast Film machinery facilities with more than 19 years of experiences.

Our company has been developing and moving towards a greater competitive advantage by continuously improving technology and innovation.

All project will be serviced by our expertise in Mechanical Engineer Department, Assembly Department, Electrical Department, Software Programming Department, so we can offer our clients with our top standard machinery, also we can make all kinds of modifications according to customer specific requirements.

Our machineries are sold in many countries including India, Indonesia, Thailand, Vietnam, Brazil, Poland, Korea, Italy, Philippines, Singapore, Russia, Malaysia, Pakistan and so on.
